Function
The support wheel axle is the core component of the support wheel assembly, mainly used for:
|
|
| |
Carrying the weight transmitted by the body through the tracks, supporting the connection between the wheels under the tracks and the track. | During the operation of the track system, it is necessary to deal with radial loads, impact loads, vibrations, mud and water intrusion and other working conditions. | Support the installation of wheel hubs, bearings, and wheel housings on the shaft to ensure the rotation of the wheels and smooth operation of the tracks |
Technical Parameters
Supporting Wheel Axle
| ITEMS | DESCRIPTION |
| Code | RVO1401130006 |
| Model | RG50 |
| Application | LOVOL AF108/RG108 series harvester |
Product Uses
In the LOVOL AF108/RG108 harvester series, if it is a tracked walking structure, the support wheel (also known as the floating wheel or support wheel) is an important component that carries the weight of the machine body and guides the operation of the track.
Product Operate Guide
During maintenance, it is important to focus on checking:
Is the shaft bent, worn, or severely scratched.
Are there any roundness or coaxiality deviations in the shaft neck and fitting diameter.
Whether the bearing installation site is deformed and whether the fit clearance is abnormal.
Are there any cracks or signs of fatigue in the installation holes and connecting structures.
Is the lubrication status of the supporting axle good, and is there any oil leakage or foreign object intrusion.
