Agricultural Autopilot GPS Automatic Steering System

This auto-steering system uses an all-in-one controller that integrates a 4G module, IMU sensor,UHF radio, and GNSS module, making it easy to install and transfer between vehicies. We eliminated the need for additional wheel angle sensors, making installation even easier.
The system delivers industry standard RTK accuracy, using a combination of GNSS and INS terrain compensation to ensure 2.5 centimeters of pass accuracy, even in difficult agricultural terrain. This accuracy and precision is valuable for a variety of agricultural activities such as furrowing, seeding and harvesting.
By eliminating overlaps and skips, fuel, seed and time can be saved while increasing yields.

Quantity:
Availability:





Inquire Add to Basket

Product Uses

Applications

Tractors for Seeding, Tillage, and Fertilization
Agricultural Sprayers
Combine Harvesters
Precision Agriculture and Farm Automation
Large-Scale Farming Operations

Key Features

Precision GPS Navigation: RTK technology ensures sub-centimeter accuracy for field operations.
Automatic Steering: Converts manual driving into fully automated navigation, reducing operator fatigue.
Easy Installation: Compatible with various agricultural machinery; plug-and-play setup.
Multi-Functional Operation: Supports straight lines, curves, and contour navigation.
Data Recording & Monitoring: Tracks field coverage, working speed, and operational efficiency.
Durable Design: Rugged construction suitable for harsh field conditions.

Product Introduction

海报01 海报03

Technical Parameters

YG AT2
AUTO STEER SYSTEM

Receiver
GPS	L1/L2/L5
GLONASS	L1/L2
Galileo	E1/E5a/E5b
BDS	B1/B2/B3
Accuracy (RTK)	Horizontal:+8mm+1ppm RMS
	Vertical:±15 mm +1 ppm RMS
Working temperature	-20℃-+70℃
Storage temperature	-40℃~+80℃
Size	159*56 mm
Network	2G/3G/4G
Dust and Waterproof	IP69K
Display
Screen	10.1
Resolution	1024*600
Brightness	750nits
I/O	2CAN,2RS232
Communication	4G,2.4GWiFi,BT4.0,USB*1
Power Supply	(9-36)VDC
Dimensions	28118142mm
Working Temperature	-20℃~+70℃
Storage Temperature	-40℃~+85℃
Dust and Waterproof	IP65
Camera
Power	DC12V±5%
Angles	120°
Pixel	1280(H) *720(V)
Dust and Waterproof	IP65
Working temperature	-20℃-+70℃
Storage temperature	-40℃-+80℃
Electric Steering Wheel
Rated Torque	7.5Nm
Max RPM	180RPM
Rated Current	15A
VO	1*CAN
Power Supply	(9-32) VDC
Dimensions of Motor	165mmx80.5mm
Dimensions of Steer Wheel	D:410mm
Working Temperature	-20℃~+70℃
Storage Temperature	-40℃~+85℃
Dustand Waterproof	IP65
*Specifications are subject to change without notice.

Product Advantage

Product Advantage

Superior performance
Versatile and powerful
Easy to install, easy to use
High Scalability and Compatibility

Superior performance

RTK and high-accuracy GPS ensure centimeter-level navigation, avoiding overlaps or missed areas.
Automatic steering reduces human errors, ensuring uniform coverage across the field.
Maintains precise navigation even on curved or irregular terrains
Learn More
Versatile and powerful

Designed to meet the diverse needs of modern agricultural Our electric-assisted steering systems are versatile and compatible with a wide range of guidance patterns, including AB Straight, A+ Line, Custom Curve and Diagonal Rake. It also supports work area statistics, work track recording, data uploading and downloading, and multi-vehicle shared operation modes.
Easy to install, easy to use

Everything is designed to be easy to use, from installation to operation.Our electric steering systems are quick and easy to install. Users only need to Frequently used functions can be activated in just a few steps, allowing the user to get started quickly and learn as they go
High Scalability and Compatibility

Compatible with tractors, sprayers, harvesters, and other agricultural machinery.
Can integrate with farm management systems for intelligent precision agriculture.
Supports future upgrades, including autonomous farm equipment and smart farming solutions

You can use a large number of additional functions to improve its performance.
