02-002-07249 Arm Fixing Slider for XAG P80 P100 P100 Pro

Product Description

Part No.: 02‑001‑09245

This load frame (application system upper frame) is a core structural support component for XAG P100 and P100 Pro agricultural drone. It serves as the mounting base for spray & spread task system, locks the tank assembly via quick‑release latches, bears heavy load during full‑tank spraying and fertilizing missions.

Hard landing, collision and long‑term heavy‑duty operation may cause frame deformation, crack or loose latch position. Replacing damaged load frame restores stable connection between flight platform and task pod, preventing swaying, offset mounting and hidden flight risks.

Why Choose Us

Selecting the right manufacturing partner is just as crucial as selecting the right part. We understand that large-scale fleet operators and regional service centers require absolute consistency, rapid availability, and uncompromising quality to keep agricultural operations running smoothly.

• Direct-from-Manufacturer Value: By streamlining the supply chain, we provide premium structural components at highly competitive rates, allowing you to optimize your maintenance budgets without sacrificing quality or safety.

• Stringent Quality Assurance: Every batch of brackets undergoes rigorous stress and dimensional testing before leaving our facilities, ensuring that every single unit you receive performs identically to the original equipment.

• Scalable Supply Capabilities: Whether you are stocking up for a seasonal overhaul or maintaining a continuous inventory for a busy repair hub, our robust production capacity guarantees you will never face debilitating stockouts.

• Expert Technical Support: Our team possesses deep knowledge of agricultural drone mechanics, ready to provide guidance on installation protocols, lifecycle management, and fleet-wide structural upgrade strategies.

Frequently Asked Questions (FAQ)

To assist procurement managers and technical maintenance teams in making informed decisions, we have compiled the most critical inquiries regarding the installation, function, and lifecycle of this front module bracket.

Q1: What is the main function of this module holder?

A: It secures and supports front-mounted modules, ensuring stable operation during flight by mitigating vibrations and bearing aerodynamic loads.

Q2: Is it compatible with other drone models?

A: It is specifically designed for XAG P100 / P100 Pro. Attempting to modify it for other chassis is not recommended as it may compromise structural integrity.

Q3: Is installation complicated?

A: No, it features a precise fit design for quick and easy installation. Technicians simply need to align it with the original mounting holes on the fuselage and secure it using standard screws and fasteners.

Q4: Do I need to replace it if damaged?

A: Yes, immediate replacement is strongly recommended if any deformation, micro-cracking, or looseness occurs to prevent catastrophic payload failure during flight.

Q5: Is this a consumable part?

A: It is a durable structural component, but regular inspection is advised under heavy use. High-intensity spraying operations expose the drone to extreme stress, making routine checks a necessary part of fleet management.

Q6: How does this bracket contribute to operational efficiency?

A: By utilizing a standardized, exact-match design, maintenance crews can replace damaged mounts in minutes in the field, significantly reducing aircraft downtime during critical planting or harvesting windows.

Specifications

• Part No：02‑002‑07249

• Applicable Model：XAG P80，P100，P100 Pro

• Usage：Fuselage‑boom locking component

• Installation：Direct replacement for original slider
