Provide structural support and positioning Position the plunger components, distribution plate, inclined plate, drive shaft, etc. along the standard axis to ensure the geometric accuracy of the hydraulic pump. | Forming a high-pressure oil circuit chamber The housing is equipped with high-pressure oil circuits, return oil chambers, and directional oil passages, corresponding to the high-pressure and low-pressure areas required for HST operation. | Carrying external installation points Including installation ears, bolt hole positions, oil port interfaces, etc., used for connecting with the harvester chassis, drive system, or hose oil circuit. | Protect internal components Housing is made of high-strength cast iron or aluminum alloy castings, with strong pressure resistance, effectively avoiding damage to internal precision parts caused by external impact or oil contamination. |
Technical Parameters
| ITEMS | DESCRIPTION |
| Name | Housing |
| Code | WHST40-03 |
| Weight | 1.48 1 piece/set |
| Size(mm) | φ(lower):36 φ(upper):25 Φ:96 H:73 |
Product Uses
Walking Drive System
Hydraulic continuously variable transmission mechanism
Small tracked combine harvester power output unit
As the core assembly, Housing is a structural component that is rarely replaced during maintenance but is crucial
Product Operate Guide
Precautions for replacement and maintenance
Housing is an irreparable part, and once cracks, deformations, or damage to the sealing surface occur, the assembly must be replaced.
When replacing, synchronous inspection is required:
Wear of distribution plate
Plunger Assembly
Slant plate wear
Bearings and oil seals
The installation must maintain cleanliness (NAS grade 8-9) to prevent particles from entering the plug holes.
Pressure and leakage tests should be conducted before starting the machine.
