Product Advantage
Product Advantage
|
The steering cylinder is usually composed of a cylinder body, piston, piston rod, seal, and end cap. When the driver operates the steering system, hydraulic oil enters different chambers of the cylinder through the pipeline, pushing the piston to move and thus driving the piston rod to rotate, achieving a change in the direction of the harvester. The sealing system of the oil cylinder ensures that the pressure of the hydraulic oil does not leak and maintains the efficient operation of the system |
Technical Parameters
| ITEMS | DESCRIPTION |
| Name | Steering Cylinder |
| Code | W2.0-05-33-01 |
| Weight | 3.2KG |
| Size(mm) | 180*128*70 |
| Application | World Harvester RUILONG PLUS 4lz-6.0p spare parts After Warranty Service Online support |
Product Uses
This model of steering cylinder is not only suitable for Wode brand harvesters, but also widely compatible with other brands of agricultural machinery, such as Kubota, Yanmar, Zoomlion, etc. For example, Kubota's DC70, DC70G, DC60, DC95, DC105 series, Yangma's AW72, AW85, YH1180 series, and Zoomlion's 4LZ=4.0ZD (PL50, PL60) series can all use this type of steering cylinder.
Product Operate Guide
Installation and maintenance recommendations
Installation: Ensure that the connection between the oil cylinder and the steering system is firm, and that there are no leaks in the hydraulic pipelines.
Maintenance: Regularly check the seals of the oil cylinder to prevent hydraulic oil leakage; Check whether the piston rod is worn or corroded; Keep the oil cylinder clean to prevent impurities from entering.
Replacement: If obvious damage or performance degradation is found in the oil cylinder, it should be replaced in a timely manner to ensure the normal operation of the steering system“
